SpECcell Polyethylene 60

• Structural expansion joints in concrete, brick, and blockwork

• Isolation joints to infill panels

• Bridge joints, abutments, pier hinge joints

• As a back-up support for sealants

• As a bond breaker for sealants over bituminous joint fillers

• Anti-vibration pads for machinery bases


• Non absorbent, closed cell

• Readily compressible

• Rot proof

• Deformable – accepts temperature cycle with minimal load transfer

• Non-tainting, suitable for potable water

• Excellent recovery after compression

• Resilient – will not distort under normal load from wet concrete

• Easily worked – can be cut with a knife

• Economical in use

• Bitumen free – no bond breaker required for sealants

• Chemical resistant – inert to most dilute acids and alkalis, resistant to oil and hydrocarbons


The technical information for SpECcell Polyethylene 60 provides essential data regarding its physical and performance characteristics:

The application of SpECcell Polyethylene 60 is essential for forming and filling expansion joints in various construction settings:

In Concrete:
SpECcell Polyethylene 60 can be placed against formwork on the concreting side prior to placing the first section of concrete. It remains in place after the removal of the formwork, allowing for the subsequent pour to be cast directly against it. The board can then be cut back later to form the sealing slot.

In Blockwork and Brick:
When laying brick or blockwork, SpECcell Polyethylene 60 should be installed to create a sealing slot of the required dimensions. This ensures proper function and performance of the joint filler within the structure.

SpECcell Polyethylene 60 is available in various sizes to meet project requirements:

• Thickness: 10mm, 15mm, 20mm, 25mm & 50mm
• Board size: 1m x 2m

The warranty for SpECcell Polyethylene 60 is limited to the replacement of the product if it is proven not to perform as described in our Technical Data Sheet. For more information regarding the warranty details, please contact our team at SMCC using any of the contact methods available on this page.
